An accurate high-capacity saw with a 1 430 W motor for building and other worksites. The dual slide system reduces the need for space, enabling the machine to be placed by a wall. The bevel lock is located at the front of the saw. Excellent dust removal function.
- Large cutting capacity in a compact design and less weight
- Less weight and compact design for job site portability
- Soft start feature for smooth start-ups
- Ergonomic rubberised D-handle design for better fit and added comfort
- Large precision machined aluminium base supports material for more efficient cutting
- Electric brake for maximum productivity
- Dust bag for a cleaner work environment
- See-through blade guard system for greater visibility of blade and line of cut
- Oversized trigger switch for better fit, added comfort and easier operation
Product Specifications:
- Capacity 90° - 91 x 310 mm
- Continuous Input Power - 1430 W
- No load speed - 4300 min⁻¹
- Capacity 45° - 91 x 215 mm
- Capacity 45° left - 50 x 310 mm
- Bevel capacity right 45° - 31 x 310 mm
- Max. Bevel Range (Left) - 45 / 45 º
- Max. Mitre Range (Left) - 47 / 60 º
- Blade Diameter - 260 mm
- Bore Size (Arbor Diameter) - 30 mm
- Power Supply Cord - 2,5 m
- Sound Power Level (LWA) - 102 dB(A)
- Sound Pressure Level (LpA) - 92 dB(A)
- Noise Uncertainty (K Factor) - 3 dB(A)
- Vibration Level (3 axes) - ≤ 2,5 m/s²
- Vibration Uncertainty (K Factor) - 1,5 m/s²
- Laser Class - 2M
- Weight Without Cable - 19,9 kg
- Product Dimensions (L x W x H): - 825 x 536 x 633 mm
